Aiko 450Wp A-MAH54Db N-Type ABC Neostar 2S+ Gen. 2 Glas-Glas Fullblack

Aiko 450Wp A-MAH54Db N-Type ABC Neostar 2S+ Gen. 2 Glas-Glas Fullblack

€70.893,90
€70.893,90
New Price NOT AVAILABLE
VAT Included.

AIKO Neostar 2S 188 (AIKO-A-MAH54Db) 440-470W

High-performance bifacial monocrystalline solar module with PERC technology

Key Specifications

Parameter Value
Power Output Range 440W-470W (front side)
Bifacial Gain Up to +25% (depending on installation)
Module Efficiency Up to 21.2%
Cell Technology Monocrystalline PERC
Cell Configuration 144 half-cells (72 cells)
Dimensions (L×W×H) 2094 × 1038 × 35 mm
Weight 25.0 kg
Power Tolerance 0 to +5%
Temperature Coefficient -0.34%/°C (Pmax)

Electrical Characteristics (STC*)

Model Variant Pmax (W) Voc (V) Isc (A) Vmp (V) Imp (A) Efficiency
440W 440 49.2 11.4 40.8 10.8 20.2%
455W 455 49.8 11.7 41.4 11.0 20.8%
470W 470 50.4 12.0 42.0 11.2 21.2%

*STC: AM1.5, 1000W/m², 25°C cell temperature

Mechanical Specifications

  • Front Glass: 2.0mm tempered, anti-reflective coating

  • Rear Glass: 2.0mm tempered

  • Frame: Anodized aluminum alloy (35mm)

  • Junction Box: IP68 rated, 3 bypass diodes

  • Cable: 4mm², 1200mm length

  • Connectors: MC4 compatible

Performance Data

Parameter Value
Bifaciality Factor 70±5%
NOCT 44±2°C
Operating Temperature -40°C to +85°C
Max System Voltage 1500V DC
Series Fuse Rating 20A
Mechanical Load Capacity 5400Pa (front), 2400Pa (rear)
Hail Resistance 25mm diameter at 23m/s

Temperature Coefficients

Parameter Coefficient
Pmax -0.34%/°C
Voc -0.28%/°C
Isc +0.05%/°C

Warranty & Reliability

  • Product Warranty: 15 years

  • Power Warranty:

    • Year 1: ≤2% degradation

    • Year 2-30: 0.45% annual degradation

    • Year 30: ≥85.6% of nominal power

  • PID resistant

  • LID <1.5%

Certifications

  • IEC 61215

  • IEC 61730

  • ISO 9001

  • ISO 14001

  • CE Mark

  • UL Listed

Packaging Information

Configuration Quantity
Pallet 28 modules
20' Container 392 modules
40' Container 840 modules

Optimal Installation

  • Recommended tilt: 20-35°

  • Minimum ground clearance: 0.5m

  • Optimal albedo surface: >50% reflectivity

  • 4-point mounting system recommended

Notes

  1. Bifacial performance depends on installation conditions

  2. All specifications based on standard test conditions

  3. Technical specifications subject to change without notice
