DAH Solar DHN-54X16-FS(BB)-435W Container

DAH Solar DHN-54X16-FS(BB)-435W Container

€46.991,56
€46.991,56
New Price NOT AVAILABLE
VAT Included.

DAH Solar DHN-54X16-FS(BB) 430-440W

High-efficiency monofacial solar module with PERC cell technology

Key Specifications

Parameter Value
Power Output 430W-440W
Module Efficiency Up to 21.2%
Cell Technology Monocrystalline PERC
Cell Arrangement 144 half-cells (54 cells)
Dimensions (L×W×H) 1722 × 1134 × 30 mm
Weight 21.5 kg
Power Tolerance 0 to +5W
Temperature Coefficient -0.35%/°C (Pmax)
Warranty 12-year product, 25-year linear power output (≥84.8%)

Electrical Characteristics (STC*)

Model Pmax (W) Voc (V) Isc (A) Vmp (V) Imp (A) Efficiency
430W 430 41.8 13.2 34.9 12.3 20.8%
435W 435 42.0 13.3 35.1 12.4 21.0%
440W 440 42.2 13.4 35.3 12.5 21.2%

*STC: AM1.5, 1000W/m², 25°C cell temperature

Mechanical Specifications

  • Front Glass: 3.2mm tempered, anti-reflective coating

  • Backsheet: Black, UV-resistant

  • Frame: Anodized aluminum alloy

  • Junction Box: IP68 rated, 3 bypass diodes

  • Cable: 4mm², 1000mm length, MC4 compatible

  • Connectors: MC4 compatible

Performance Data

Parameter Value
NOCT 45±2°C
Operating Temperature -40°C to +85°C
Max System Voltage 1500V DC
Series Fuse Rating 20A
Front Load Capacity 5400Pa (static)
Snow Load Capacity 4000Pa
Hail Resistance 25mm diameter at 23m/s

Temperature Coefficients

Parameter Coefficient
Pmax -0.35%/°C
Voc -0.27%/°C
Isc +0.05%/°C

Certifications

  • IEC 61215

  • IEC 61730

  • ISO 9001

  • ISO 14001

  • CE Mark

  • UL Listed

Packaging Information

Configuration Quantity
Pallet 30 modules
20' Container 480 modules
40' Container 960 modules

Warranty & Reliability

  • Product Warranty: 12 years

  • Power Warranty:

    • Year 1: 97% of nominal power

    • Year 2-25: 0.55% annual degradation

    • Year 25: ≥84.8% of nominal power

  • PID resistant

  • LID <1.5%

Notes

  1. All specifications are subject to change without prior notice

  2. Actual performance may vary based on installation conditions

  3. For optimal performance, follow recommended installation guidelines
