DAH Solar

DAH Solar DHN-60R18/FS(BW)-510W Container

DAH Solar DHN-60R18/FS(BW)-510W Container

€59.119,39
€59.119,39
New Price NOT AVAILABLE
VAT Included.

DAH Solar DHN-60R18-FS(BW) 500-520W

High-efficiency bifacial solar module with n-type TOPCon technology

Key Specifications

Parameter Value
Power Output 500W-520W
Module Efficiency Up to 22.1%
Cell Technology n-type TOPCon
Bifaciality Factor 80±5%
Cell Arrangement 120 half-cells (60 cells)
Dimensions (L×W×H) 1762 × 1134 × 30 mm
Weight 23.5 kg
Power Tolerance 0 to +5W
Temperature Coefficient -0.29%/°C (Pmax)
Warranty 15-year product, 30-year linear power output (≥87.4%)

Electrical Characteristics (STC*)

Model Pmax (W) Voc (V) Isc (A) Vmp (V) Imp (A) Efficiency
500W 500 44.2 14.8 37.0 13.5 21.5%
510W 510 44.5 14.9 37.3 13.7 21.8%
520W 520 44.8 15.1 37.6 13.8 22.1%

*STC: AM1.5, 1000W/m², 25°C cell temperature

Mechanical Specifications

  • Front Glass: 2.0mm tempered, anti-reflective coating

  • Rear Glass: 2.0mm tempered

  • Frame: Anodized aluminum alloy (35mm)

  • Junction Box: IP68 rated, 3 bypass diodes

  • Cable: 4mm², 1200mm length, MC4 compatible

  • Connectors: MC4 compatible

Performance Data

Parameter Value
NOCT 43±2°C
Operating Temperature -40°C to +85°C
Max System Voltage 1500V DC
Series Fuse Rating 20A
Front Load Capacity 5400Pa (static)
Rear Load Capacity 2400Pa (static)
Hail Resistance 25mm diameter at 23m/s

Temperature Coefficients

Parameter Coefficient
Pmax -0.29%/°C
Voc -0.24%/°C
Isc +0.04%/°C

Bifacial Performance

  • Bifacial Power Gain: Up to 30% (depending on installation conditions)

  • Recommended Installation:

    • Ground clearance ≥0.5m

    • Tilt angle 15-35°

    • High albedo surfaces preferred

Certifications

  • IEC 61215

  • IEC 61730

  • ISO 9001

  • ISO 14001

  • CE Mark

  • UL Listed

Packaging Information

Configuration Quantity
Pallet 30 modules
20' Container 480 modules
40' Container 960 modules

Warranty & Reliability

  • Product Warranty: 15 years

  • Power Warranty:

    • Year 1: ≤1% degradation

    • Year 2-30: 0.4% annual degradation

    • Year 30: ≥87.4% of nominal power

  • PID resistant

  • LID <1%

Notes

  1. Bifacial gain varies with installation conditions (albedo, mounting height, tilt angle)

  2. All specifications subject to change without notice

  3. For optimal performance, follow manufacturer's installation guidelines
