DHN-60R18-FS(BB)-500W

DHN-60R18/FS(BB) 500-520W Full-Screen Single Glass PV Module

The DHN-60R18/FS(BB) is a high-efficiency, N-type TOPCon solar module featuring patented Full-Screen Technology to maximize energy output and reduce maintenance. With a power range of 500W to 520W, this module is designed for optimal performance, cost savings, and durability in diverse environments.

Key Features:

• Full-Screen Technology: Eliminates dust and snow accumulation, boosting power generation by 6-15% compared to traditional modules.

• High Efficiency: Up to 23.00% module efficiency (STC) with N-type TOPCon cells, offering lower attenuation, better temperature coefficients, and superior low-light performance.

• Cost-Effective Design: Rectangular cells (182mm × 95.8mm) optimize space, reducing BOS costs (balance of system) for brackets and cables.

• Enhanced Logistics: 5.4% higher container loading capacity (748 modules per 40HQ) lowers transportation costs.

• Durable & Reliable: 30-year linear power output warranty ensures long-term performance, with 90% power retention after 10 years and 87.4% after 30 years.

• Certified Quality: Compliant with IEC 61215, IEC 61730, CE, INMETRO, and ISO standards (9001, 14001, 45001) for quality, environmental, and safety compliance.

Technical Specifications:

• Dimensions: 1994 × 1134 × 32mm

• Weight: 21.7kg

• Cell Configuration: 120 cells (6×20)

• Maximum System Voltage: 1500V DC

• Operating Temperature: -40°C to +85°C

• Snow/Wind Load Resistance: 5400Pa (front) / 2400Pa (back)

• Packing: 34 modules per pallet, 748 modules per 40HQ container.

Electrical Performance (STC):

• Maximum Power (Pmax): 500–520W

• Open-Circuit Voltage (Voc): 43.7–44.5V

• Short-Circuit Current (Isc): 14.48–14.72A

• Temperature Coefficients:

  • Pmax: -0.29%/°C

  • Voc: -0.25%/°C

  • Isc: +0.046%/°C

Ideal Applications:

• Commercial and industrial rooftops

• Utility-scale solar projects

• Areas prone to dust or snow accumulation

• Projects requiring high logistics efficiency and lower LCOE (Levelized Cost of Energy)
